Best Monitor Settings for PS5 Pro and Xbox Series X (120Hz, VRR, ALLM)

The PlayStation 5 Pro and Xbox Series X have transformed console gaming, bringing high-fidelity 120 FPS performance, low-latency Variable Refresh Rate (VRR), and crystal-clear 1440p/4K output to competitive gamers.

However, console display settings operate differently than PC graphics drivers. Connecting a console to a 144Hz or 240Hz PC monitor often leaves users confused about why 120Hz is grayed out or why HDR looks washed out. Here is the definitive setup guide.

Console Feature Comparison: PS5 Pro vs. Xbox Series X

Optimal PlayStation 5 Pro Configuration

1. Navigate to Settings → Screen and Video → Video Output.
2. Set Resolution to 2160p (or 1440p if using a 1440p native panel).
3. Set VRR to Automatic, and toggle Apply to Unsupported Games to ON.
4. Set 120 Hz Output to Automatic.
5. Set ALLM to Automatic.
6. Navigate to Saved Data and Game/App Settings → Game Presets and set Performance Mode as default.

Optimal Monitor OSD Settings for Consoles

• Overdrive / Response Time: Set to "Normal" or "Fast" (never "Extreme" or "Fastest"). Consoles run at 60Hz and 120Hz, where aggressive overdrive voltages cause excessive pixel overshoot artifacts.
• Color Format: Set monitor input color format to RGB Full (0-255).
• HDR Mode: Select HGiG or Custom HDR. Avoid dynamic contrast boosters.
